Genuino

Arduino M0

Arduino M0

Regular price $29.00 USD
Regular price Sale price $29.00 USD
Sale Sold out
Shipping calculated at checkout.

With the new Arduino M0 board, the more creative individual will have the potential to create one’s most imaginative and new ideas for IoT devices, wearable technologies, high tech automation, wild robotics and other not yet thinkable adventures in the world of makers. The Arduino M0 represents a simple, yet powerful, 32-bit extension of the Arduino UNO platform. The board is powered by Atmel’s SAMD21 MCU, featuring a 32-bit ARM Cortex® M0 core. With the addition of the M0 board, the Arduino family becomes larger with a new member providing increased performance. The power of its Atmel’s core gives this board an upgraded flexibility and boosts the scope of projects one can think of and make; moreover, it makes the M0 the ideal educational tool for learning about 32-bit application development.

Specification

MicrocontrollerATSAMD21G18, 48pins LQFP
ArchitectureARM Cortex-M0+
Operating Voltage3.3 V
Input Voltage (recommended)from 5 to 12 Volts
Digital I/O Pins20
PWM Digital I/O Pins12
Analog Input Pins6, 12-bit ADC channels
Analog Output Pins1, 10-bit DAC
DC Current per I/O Pin7 mA
Flash Memory256 KB
SRAM32 KB
Clock Speed48 MHz
Power Consumption29 mA
PCB Size53 mm x 68.5 mm
Weight21 g
